• Engine type: Scania - DC09 137/320 hp
• Number of cylinders: 5
• Power: 320 hp (235 kW) at 1900 rpm
• Engine displacement: 9,300 cc
• Max. torque: 1,600 Nm at 1050-1300 rpm
• Equipped with a turbocharger and an intercooler
• Emission rating: Euro 4, equipped with SCR, DPF, and common rail fuel injection system
• Engine layout: In-line, longitudinal along chassis
• Strong protective guard at the rear of the chassis and under the engine to protect against potential collisions
• Replaceable oil filter and washable centrifugal oil cleaner
• Front axle: Two air bellows + two shock absorbers
• Second axle: Four air bellows + four shock absorbers
• Third axle: Two air bellows + two shock absorbers
• Electronic level control to adjust the body ground clearance. The vehicle returns to normal level automatically for more safety when the speed exceeds 30 km/h.
• Kneeling system for easy passenger boarding and alighting
• Passenger Capacity:
- 47 seated
- 51 standing + 1 wheelchair
- 59 standing (without wheelchair)
• Overall Length: 14,801 mm
• Overall Width: 2,550 mm
• Overall Height including AC: 3,216 mm
• Wheelbase: 6,830 mm
• Front Overhang: 2,930 mm
• Rear Overhang: 5,041 mm
• Front Axle Weight Limit: 7,100 kg
• Second Axle Weight Limit: 11,500 kg
• Third Axle Weight Limit: 6,000 kg
• Curb Weight: 24,600 kg
• Fuel Tank Capacity: 220 liters
• AdBlue Tank Capacity: 45 liters
• Doors: Three double-leaf pneumatic doors on one side
• Two 150-Amp 24-Volt alternators
• Two 12-Volt 230 Ah batteries
• Multiplex (CAN) electrical system for reduced wiring, easy troubleshooting, and protection against tampering
• Disc Brakes for Front and Rear Wheels (with separate air reservoir)
• EBS (Electronic Braking System) and ABS (Anti-lock Braking System)
• Automatic Exhaust Brake
• TC (Traction Control)
• Door Safety System: Automatic door closing above 5 km/h, with anti-pinch auto-reopen function
