• Engine Model: WP10.336E53
• Manufacturer: WEICHAI POWER
• Engine Type: 6-cylinder in-line engine, with water cooling system and turbocharger
• Type of Fuel: CNG
• Maximum Power: 336 hp
• Maximum Torque: 1450 Nm at 1200 to 1500 RPM
• Engine Displacement: 9.726 liters
• Emission Standard: Euro 5 + EEV
• Governed Speed: 90 km/h
• Transmission: Automatic VOITH gearbox with hydraulic retarder
• Front Axle: 7.5-ton DONGFENG DANA
• Rear Axle: 13-ton DONGFENG DANA
• Suspension System: Air suspension, 2 telescopic shock absorbers at the front + 4 telescopic shock absorbers at the rear, kneeling system
• Steering: Bosch 8098, adjustable steering wheel
• Braking System: Dual circuit air brakes, disc brakes, ABS (Anti-lock Braking System) + ASR (Anti-Slip Regulation) + EBS (Electronic Braking System) WABCO
• Gas Tanks: Type 4 tanks - 6×160 liters with standard R110
• Tires: 275/70R22.5
• Battery/Alternator: Two 195 Ah maintenance-free batteries / Bosch alternator, 150A+150A, 24V
• Additional Features: Automatic engine temperature control system
.jpeg)
• Robust, standards-compliant structure
• CO₂ shielded welding compliant with ISO 3834 standards
• Fully coated structure with zinc chromate primer and underbody insulation for corrosion protection
• Low-entry design for easy passenger boarding and alighting
• Standards-compliant thermal and acoustic insulation for floor, walls, and ceiling
• Body panels constructed from automotive-grade steel
• Front and rear double-leaf aluminum pneumatic inward-opening doors
• Pneumatic door safety system with anti-pinch protection
• Automatic door closing upon vehicle movement
• CAN bus system
• Water- and heat-resistant insulation for electrical components and cable harnesses
• Sealed fuse box, isolated from battery compartment, moisture- and dust-resistant
•Engine compartment fire detection system
