• Engine Model: WP10.336E53
• Manufacturer: WEICHAI
• Engine Type: 6-cylinder in-line diesel engine
• Maximum Power: 336 hp
• Maximum Torque: 1550 Nm
• Engine Displacement: 9.7 liters
• Emission Standard: Euro 5 + EEV
• Governed Speed: 90 km/h
• Cooling System: Electric fan with Smart Engine Temperature Control (ATS)
• Overall Length: 12,947 mm
• Overall Width: 2,550 mm
• Overall Height: 3,194 mm
• Approach and Departure Angles: 6°-7°
• Front Axle Weight Limit: 7.5 tons
• Rear Axle Weight Limit: 13 tons
• Curb Weight: 13,514 kg
• Passenger Capacity (without wheelchair): 39+1 seated (53 standing)
• Passenger Capacity (with wheelchair): 39+1 seated (45 standing)
• Robust, standards-compliant structure
• CO₂ shielded welding compliant with ISO 3834 standards
• Fully coated structure with zinc chromate primer and underbody insulation for corrosion protection
• Low-entry design for easy passenger boarding and alighting
• Robust rear chassis and engine underguard for enhanced safety
• Body panels constructed from galvanized automotive-grade steel
• Standards-compliant thermal and acoustic insulation for floor, walls, and ceiling
• Oven-baked paint resistant to extreme temperatures, with customizable colors
• Rear double-leaf aluminum pneumatic inward-opening doors on both sides
• Front double-leaf inward-opening door
• Pneumatic door safety system with anti-pinch protection
• Automatic door closing upon vehicle movement
• Opposed-motion windshield wipers
• 6-liter windshield washer fluid reservoir
• LCD monitor
• MP5 multimedia system with FM radio, audio/video playback, and monitor output
• Internal and external digital displays
• Two 200 Ah 12-Volt batteries
• Two 150-amp 24-Volt alternators
• CAN bus system
• Water- and heat-resistant insulation for electrical components and cable harnesses
• FMS (Fleet Management System)
• AVL (Automatic Vehicle Location) and AFC (Automatic Fare Collection) systems
• Engine compartment automatic fire detection and suppression system
• Battery compartment fire alarm system
• Vehicle lighting system compliant with European standard R48
• Blue and white LED interior lighting
• Exterior lighting with automatic lighting (AL) and daytime running lights (DRL)
• Front and rear fog lights
